Bachmann IT PDU 19 inch FuseBox 6x MCB 1U (800.0120)
The Bachmann 19inch Fusebox 800.0120 offers a space-saving option of splitting a 32A / 400V infeed between two 16A / 400V infeeds.
Bachmann IT PDU 19" FuseBox 6x MCB 1U (800.0120)
The Bachmann 800.0120 Fusebox offers a space-saving option of splitting a 32A / 400V infeed between two 16A / 400V infeeds and complements thus perfectly the Bachmann IT PDU power strips for the integration into serverracks.
Key features Bachmann IT PDU 19inch FuseBox 6x MCB 1U (800.0120)
- 19" fusebox (32A / 400V / 50 Hz)
- Splits a 32A / 400V infeed between two 16A / 400V infeeds
- 6x 16 A miniature circuit breakers (MCB) with characteristic C
- Plug: 3x CEE 32A
- Phase(s): 3
- Rated voltage: 400V
- Current per phase: 32A
- Cable type: 2.0 m H05VV-F 3G 1.50 mm²
Note DGUV V3: According to DGUV V3, permanently screwed / stationary power strips must be checked every 4 years by a qualified electrician in accordance with DIN VDE 0100-600. Portable power strips must be checked annually. Further information can be found in the download area under "Manufacturer's declarations"
| Product sheet: |  [pdf, 1,2 MB] |
|---|---|
| RoHS / REACH: | [pdf] |
| Warning/safety instructions: | [pdf] |
| Contains installation material: | + |
| Manufacturer/Importer: | Bachmann GmbH, Ernsthaldenstr. 33, 70565 Stuttgart, info@bachmann.com |
| color: | Others |
| Land: | Germany |
| screw-on: | Yes |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
