Crestron DigitalMedia Presentation System 200-C Series-3

Crestron DigitalMedia Presentation System 200-C Series-3

Crestrons DMPS3-200-C provides a complete, high-resolution presentation control and signal routing solution for classrooms, boardrooms, lecture halls, and video conferencing rooms. It is a 7x4 system switch. It integrates the control system, multi-format matrix switch, microphone mixer, audio DSP and amplifier in a 3RU server cabinet package. The DMPS3-200-C provides extensive signal routing flexibility and powerful signal processing without the need for separate components. Automatically configurable inputs allow plug and play compatibility with a variety of digital and analog sources. The integrated DigitalMedia 8G+ and HDBaseT connectivity provides an optimized remote wiring solution for external sources and displays, as well as for the entire facility as part of a larger media distribution system.

Technical Details DigitalMedia Presentation System DMPS3-200-C

• Housing material: metal
• Front: metal with polycarbonate coating
• Color: Black
• Dimensions (LxWxH): 483 x 415 x 133 mm
• Installation in 19 inch server cabinet possible / 3 HE
• Working temperature: 5 ° C - 40 ° C
• Weight: 7.5 kg
• SDRAM: 512 MB
• Flash memory: 4 GB
• 5 HDMI inputs / 1 output
• 4 MIC inputs
• 1 Gigabit Ethernet In / 1 Ethernet Out
• 10 programs simultaneously executable
• ExFAT file system
• HDMI supports resolutions up to 165MHz

More about Crestron DigitalMedia Presentation System DMPS3-200-C

This Crestron product does not meet your requirements? We are happy to advise you individually on this product. Do not hesitate to contact us.
