Ergotron LX monitor mount for 3 monitors 40 inch, white (45-509-2163)
Monitor mount for 3 monitors
The Ergotron LX triple monitor mount (45-509-2163) in white is equipped with three generously adjustable swivel arms that, in conjunction with the tall column, allow for an individual arrangement of the monitors. The three monitor arms are designed for a weight of 6.6 kg each and are suitable for a maximum diagonal of 40 inches. Thanks to separate height adjustment, swivel, tilt and rotate function (portrait - landscape), a high ergonomic comfort with a positive effect on the posture is achieved. The monitor mount for 3 monitors can be installed either by desk clamp or as a through-screw attachment on almost all common desks. The integrated cable guide ensures a tidy overall appearance. Optionally, the column can be expanded to a quadruple mount with an additional LX arm, which is available separately. Please note that this reduces the load capacity of the individual monitor arms proportionally.
Key features Ergotron LX triple monitor desk holder (45-509-2163)
- Screen size: max. 40 inch
- High column for 3 monitors side by side or one above the other
- Load capacity: 20 kg (6.6 kg per monitor)
- Max. monitor height when arranged one above the other: 530 mm
- Max. Monitor width with 3 monitors side by side: 525 mm
- Max. Monitor width with 2 monitors side by side: 1020 mm
- VESA mount: 75x75, 100x100 mm
- Height adjustable: 330 mm
- Tilt: +5° / -70°
- Swivel: 360 degrees
- Rotatable: 360° (pivot)
- Mounting type: desk clamp (tabletop thickness: 16 - 66 mm) or screw-through mounting (tabletop thickness: max. 76 mm)
- Integrated cable management
- Optional extension to quad monitor mount with LX monitor arm 98-130-216 (load capacity with 4 arms: 5 kg per monitor)
- Material: aluminum, steel
- Warranty: 10 years
- Color: white
- Product consisting of:
- 1x Ergotron LX dual monitor desk mount (45-509-216)
1x Ergotron LX accessory extension monitor arm (98-130-216)
- 1x Ergotron LX dual monitor desk mount (45-509-216)
Does your display fit the monitor mount?
We would be happy to check whether your monitor is suitable for this Ergotron LX triple monitor holder (45-509-2163). Just tell us your model (manufacturer + model no.) in the comment field at the end of the order process. We will then check for you whether the monitor or the display fits the monitor mount and if not, we will contact you.
VESA standard - Read more about the VESA standards of monitor brackets!
| Product sheet: |  [pdf] |
|---|---|
| Technical drawing: | [pdf] |
| Installation manual: | [pdf] |
| Capacity: | 20 kg (6.6 kg per monitor) |
| Tilt: | +5° / -70° |
| Rotate: | 90° |
| Height range (mm): | 330 |
| Pivot: | 90° |
| Swivelling range: | 360° |
| Length of the swivel arm: | 609 |
| Screen size: | 15 - 40" |
| Thickness of table (mm): | 16 - 66 (desk clamp) | 76 (screw-through mounting) |
| Material: | Aluminum, steel |
| VESA Standard: | 75x75, 100x100 mm (www.vesa-standard.com) |
| Accessories: | Ergotron LX monitor arm 98-130-216 |
| Packaging dimensions (LxWxH in mm): | 180 x 450 x 760 | 440 x 200 x 170 |
| Scope of delivery: | 1x dual monitor mount 45-509-216 | 1x LX monitor arm 98-130-216 | installation material |
| Contains installation material: | + |
| Warranty: | 10 years |
| Manufacturer/Importer: | Ergotron Europe, Stationsstraat 77H, 3811 MH Amersfoort, Niederlande, info.de@ergotron.com |
| Inch size: | 15 inch, 17 inch, 18 inch, 19 inch, 20 inch, 21 inch, 22 inch, 23 inch, 24 inch, 25 inch, 26 inch, 27 inch, 28 inch, 29 inch, 30 inch, 31 inch, 32 inch, 34 inch, 35 inch, 37 inch, 38 inch, 40 inch |
| Mobility: | height adjustable , rotatable (pivot), swivelling, tilting |
| Mounting type: | desk - clamp, desk - drill screw fastening |
| Multi-monitor mount: | Triple solution |
| color: | Weiß |
| VESA (in mm): | VESA 75x75, VESA 100x100 |
Note on Curved Monitors:
If a curved suitability is not explicitly mentioned with the mount, we do not guarantee that the mount is suitable for curved screens. We are happy to check the compatibility for you! Write us an email with your TV model and the desired monitor mount!
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
