EVOline Circle80 built-in socket with USB charger A/C, cable routing, black
Built-in socket with USB charger A/C, cable outlet and cover / cable routing
The EVOline Circle80 built-in sockets modernize your desk by combining cables and charging options to save space. With the built-in socket in black with USB double charger A/C, fast charging is guaranteed thanks to supported charging protocols. The bezel with cable grommet keeps necessary cables in their place and keeps your desk tidy. This practical table connection panel can be installed in worktops, in the desk, in the office or in the kitchen. The socket outlet with USB-A and USB-C connection in black has a 3 m long connection cable with an angle plug
Quick and easy assembly
The flat Circle80 built-in socket is installed flush with the surface up to 5.5 mm, has a circumference of 92 mm and integrates flat into the environment wherever you need it. Built-in sockets are practical helpers in worktops, on desks, in the office and in the kitchen. A simple turn of a screw is sufficient for safe installation in worktops from a thickness of 10 mm, a maximum worktop thickness is not specified.
Technical details EVOline Circle80
- Colour: black
- Bezel: black with cable routing (2x 4, 7 and 9mm each)
- Material: plastic
- Installation opening: Ø 79 mm
- Installation depth: 48.5 mm
- 3 m mains connection cable with right angle plug with earthing contact
- 1x USB-A, 1x USB-C with 2.1 each A and 5 V
- Quick and easy installation
- Voltage 230V AC
- Supported charging protocols:
- USB battery charging (USB BC)
- Revision 1.2 (downwards compatible)
- Charging capacity: 2A (Apple iPhone, Apple iPad, Samsung Galaxy Tablet)
- China YD/T1591-2009 Load Specification
- Testing according to the new DIN VDE 0620
| Product sheet: |  [pdf, 589 kb] |
|---|---|
| Technical drawing: | [pdf, 546 kb] |
| RoHS / REACH: | [pdf, 1,3 MB] |
| Installation manual: | [pdf, 1,3 MB] |
| Suitable for: | For worktops from 10 mm thick |
| Packaging dimensions (LxWxH in mm): | 260 x 140 x 150 |
| Scope of delivery: | 1 x EVOline Circle80, 1 x bezel cable guide |
| Manufacturer/Importer: | Schulte - Elektrotechnik GmbH & Co. KG / EVOline, Jüngerstraße 21, D-58515 Lüdenscheid, info@schulte.com |
| Number of sockets: | 1 |
| color: | Black |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
