EVOline Square80 with Qi option with CAT6 socket stainless steel
The EVOline Square80 with Qi charging function and with CAT 6 socket with stainless steel effect cover and black housing with 3 m fixed supply cable provides a socket, a USB-Charger and a CAT6 socket inside the 80 mm diameter. The sliding cover provides an inductive technology (standard WPC 1.1) for wireless charging of suitable mobiles.
EVOline Square 80 Qi option 1x socket, 1x USB and 1x CAT6 socket stainless steel
Cable apertures in desks are standard. This standard opening in the work surface can offer you more than just a hole with cover. EVOline Square provides a socket, a USB-Charger and a data connection inside the 80 mm diameter. Even in closed position EVOline Square80 gives you a smart offer: The sliding cover in its QI-Version provides an inductive technology (standard WPC 1.1) for wireless charging of suitable mobiles.
Key features EVOline Square80 QI-Version with CAT6 socket
- Installation for surface thickness of up to 50 mm
- Installation cutout diameter: 80 mm
- Configuration:
1x power outlet, VDE compliant, 16 A, touch-protected
1x USB type A charger – ideal for charging of all USB-chargeable devices
1x CAT 6 socket (RJ45) - Output voltage: 5V DC
- Rated output voltage: 1A
- 3 m fixed supply cable with socket angled plug (RJ45)
- Stainless steel effect cover and black housing
- With Qi charging function (standard WPC 1.1) for wireless charging of suitable mobiles
| Product sheet: |  [pdf, 615 kb] |
|---|---|
| Technical drawing: | [pdf, 241 kb] |
| RoHS / REACH: | [pdf] |
| Installation manual: | [pdf, 714 kb] |
| Suitable for: | Für Tischstärken bis 50 mm |
| Packaging dimensions (LxWxH in mm): | 340 x 240 x 180 |
| Scope of delivery: | 1x EVOline Square80 |
| Contains installation material: | + |
| Manufacturer/Importer: | Schulte - Elektrotechnik GmbH & Co. KG / EVOline, Jüngerstraße 21, D-58515 Lüdenscheid, info@schulte.com |
| Number of sockets: | 1 |
| color: | Stainless Steel |
| USB-Charger: | USB-A |
| Land: | Germany |
| screw-on: | Yes |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
