LEICKE KN40646 KanaaN HDMI splitter 4K to 2x HDMI outputs
The new LEICKE KanaaN 4K 1x2 HDMI splitter on 2x HDMI outputs allows you to connect two devices, such as beamer and UHD-TV, to a source such as UHD receivers, Blu-Ray players or game consoles such as the PS4 or Xbox One. Successor of the LEICKE KN40546 KanaaN 4K 1x2 HDMI splitter.
LEICKE KanaaN 4K 1x2 HDMI splitter to 2x HDMI outputs
This new edition of LEICKE KanaaN 4K splitter allows you to connect two devices, such as beamer and UHD-TV, to a source, such as a projector, UHD receivers, Blu-Ray players or game consoles such as the PS4 or Xbox One.
The incoming HDMI signal is multiplied and is synchronized at both outputs. This makes the KanaaN 2-way splitter ideal as a distributor for home cinema installations or if you want to play several rooms at the same time.
Thanks to the professional design and compatibility with current standards, the LEICKE splitter is suitable for reliable, future-proof cabling.
Key features LEICKE KanaaN 4K HDMI splitter 1x to 2x HDMI outputs
- Supported resolutions (input): 2160p (UHD, 4K), 1080i/p (Full HD), 780i/p (HD), 576i/p (PAL), 480i/p (VGA, wide VGA) output up to 60Hz
- 3D support, color depth max. 48 bit
- HDMI 1.4b compatible
- Audio formats: LPCM, DTS, DTS-HD, Dolby Digital, Dolby True HD, 2Ch, 5.1Ch, 7.1Ch
- Power supply: 5V 1A
- Max. cable length: 15m AWG26 (depends on cable quality)
- Compact, modern housing design
- The highest possible resolution is equal to the lowest resolution in the setup!
Delivery content LEICKE KanaaN 4K HDMI splitter 1x HDMI input to 2x HDMI outputs:
- LEICKE KanaaN 1x2 splitter for UHD 4K
- 5V power supply with 1A max. 100 ~ 240V input voltage
| Installation manual: |  [pdf] |
|---|---|
| Contains installation material: | + |
| Manufacturer/Importer: | Leicke GmbH, Stöhrerstraße 17, 04347 Leipzig, info@leicke.com |
| color: | Silver/Anthracite |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
