Comount Dual USB built-in charger with USB-A/C, open cable ends
Highlights
- USB-A and USB-C dual-port
- Quick Charge and Power Delivery
- 2 x 18 W output power
- Installation diameter only 27 mm
- Ideal for caravans and boats
USB built-in charger with fast-charging function for vehicles and furniture
The Comount Dual USB built-in charger with USB-A/C, open cable ends is the ideal charging solution for those who do not want to do without fast charging on the go or in interior fittings. The high-quality built-in charger features a USB-A and a USB-C port, both equipped with high-speed charging technology. Thanks to Quick Charge (QC) and Power Delivery (PD), smartphones, tablets or rechargeable lights are charged in no time. With an output power of 18 W per port, the Comount 560001 provides reliable power for two devices simultaneously.
The compact Dual USB built-in charger can be flexibly integrated into a variety of surfaces up to 17 mm thick with a mounting diameter of only 27 mm. Whether in motorhomes, caravans, boats or in furniture – the open cable ends with 150 mm cable length allow individual installation. The charger is compatible with the switch programs from Berker and Inprojal and offers comprehensive protection against short circuit, overheating and overvoltage. A dust cover can be added optionally. Ideally suited for use in vehicles, on boats, in workshops or in furniture installation.
Technical details – Comount USB-A USB-C built-in charger
- Input voltage: 12-24 V DC
- Output power: 2 x 18 W
- USB-A: 5.0 V / 3 A, 9.0 V / 2 A, 12.0 V / 1.5 A – QC3.0, QC 2.0, FCP, DCP, BC 1.2, AFC, SCP
- USB-C: 5.0 V / 3 A, 9.0 V / 2 A, 12.0 V / 1.5 A – PD 3.0, QC 3.0, QC4.0, AFC, FCP, BC 1.2, DCP, SCP
- Current in standby mode: 5-7 mA
- Operating temperature: -20 °C to +70 °C
- Storage temperature: -40 °C to +90 °C
- Weight: 32 g
- Front diameter: 36 mm
- Mounting diameter: 27 mm
- Mounting depth: 39.5 mm
- Compatible with switch programs from Berker and Inprojal
- Suitable for surfaces up to 17 mm thick
- Open cable ends, cable length 150 mm
- Protection against short circuit, overheating and overvoltage
- Standards: CE, UKCA, RoHS, REACH, ECE-R10
| Scope of delivery: | 1x Dual USB built-in charger with open cable ends |
|---|---|
| Contains installation material: | + |
| Manufacturer/Importer: | RAM Mounts Germany GmbH, Alexander-Meissner-Str. 42, 12526 Berlin, info@rammounts.de |
| color: | Black |
| USB-Charger: | USB A/C |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
Download area - catalogs, flyers, warranty conditions, ...
Questions & Answers
-
What is the Comount Dual USB In-dash Charger with USB-A / USB-C?
A compact dual USB in-dash charger designed for use in vehicles and furniture, with open cable ends and two ports delivering 18 W each. USB-A and USB-C support Quick Charge and Power Delivery.
-
Which ports and charging standards are supported?
USB-A: 5V/3A, 9V/2A, 12V/1.5A – QC3.0, QC2.0, FCP, DCP, BC1.2, AFC, SCP; USB-C: 5V/3A, 9V/2A, 12V/1.5A – PD3.0, QC3.0, QC4.0, AFC, FCP, BC1.2, DCP, SCP.
-
What are the input and output specifications?
Input range: 12–24 V DC; Output: 2 × 18 W.
-
How is it wired and installed? What are the dimensions?
Open cable ends are 150 mm long; mounting diameter 27 mm; front diameter 36 mm; mounting depth 39.5 mm; suitable for surfaces up to 17 mm thick.
-
What protection features does it have?
Protection against short circuit, overheating and overvoltage; optional dust protection.
-
What certifications does it have?
CE, UKCA, RoHS, REACH, ECE-R10.
-
Where can it be used and what is the compatibility?
Compatible with Berker and Inprojal switch programs; suitable for use in vehicles, motorhomes, caravans, boats, workshops or furniture.
What advantages does a USB built-in charger offer in a motorhome or boat?
Anyone who spends a lot of time in a motorhome, caravan or boat knows the problem: the number of power outlets is limited, and conventional power adapters take up unnecessary space. A permanently installed USB built-in charger provides a remedy. It is mounted directly into the surface and reliably supplies power via USB-A and USB-C for smartphones, tablets, cameras or rechargeable lights. Integration into the existing 12–24 V on-board network makes separate adapters unnecessary. This is a huge advantage, especially in confined spaces such as a motorhome or on a boat. The Comount Dual USB built-in charger USB-A and USB-C (560001) was developed specifically for such applications. With an installation diameter of only 27 mm it fits into almost any console, work surface or switch panel. The open cable ends allow flexible wiring so that the charger can be easily integrated into existing installations. Compatibility with the switch programs from Berker and Inprojal also allows it to blend harmoniously into modern interiors.
How fast does the Comount 560001 USB built-in charger charge smartphones and tablets?
Charging speed is a decisive criterion when choosing a built-in charger. The Comount 560001 supports current fast-charging standards with Quick Charge 3.0 and Power Delivery 3.0. Both ports provide up to 18 W output each, so compatible devices charge significantly faster than on conventional USB ports. The USB-A port is compatible with numerous protocols, including QC 2.0, QC 3.0, FCP, AFC and SCP. The USB-C port additionally supports PD 3.0 and QC 4.0. This means the built-in charger covers virtually all common smartphone and tablet manufacturers. Whether iPhone, Samsung Galaxy, iPad or Huawei — the appropriate fast-charging technology is automatically detected and activated. Both ports can be used simultaneously without any significant drop in charging performance. This makes the Comount 560001 an ideal solution when multiple people want to charge their devices at the same time.
Where can the dual USB built-in charger be used?
The applications of the Comount Dual USB built-in charger go far beyond vehicles and boats. Thanks to its compact design, it is equally suitable for installation in desks, kitchen countertops, bedside tables or workbenches. Wherever a fixed USB charging station is desired, the 560001 offers an elegant and functional solution. The small installation diameter of 27 mm and the installation depth of only 39.5 mm allow mounting even in thin surfaces up to 17 mm thick. The input voltage of 12 to 24 V DC ensures that the charger can be used both in the 12 V on-board network of a car and in the 24 V system of a truck or commercial vehicle. Integrated protection against short circuit, overheating and overvoltage ensures safe operation. The low standby current draw of only 5 to 7 mA conserves the battery during prolonged periods of inactivity. With certifications CE, UKCA, RoHS, REACH and ECE-R10 Type Approval, the Comount USB built-in charger meets all relevant European standards and safety regulations.
