RAM Mounts GDS hardwire charger with USB-C (45W), SAE connector, 10–30V DC input (RAM-GDS-CHARGE-V3C-3U)
Highlights
- USB-C GDS hardwire charger with 45W PD
- SAE connector, input 10-30V DC
- Output 5-15V DC, 3A max.
- Protection against overvoltage & short-circuit
- Certified: FCC, CE, RoHS, UL
RAM Mounts GDS Hardwire Charger USB-C with Power Delivery for Vehicles
The RAM Mounts GDS Hardwire Charger RAM-GDS-CHARGE-V3C-3U is the ideal solution for powering compatible USB-C GDS vehicle mounts. The hardwire charger connects to the vehicle power source via the SAE connector and reliably supplies power to your devices. It supports USB Power Delivery 3.0 (45W), making it particularly suitable for power-hungry devices such as tablets or rugged industrial handhelds.
With a wide input voltage range of 10-30V DC, the RAM Mounts GDS Hardwire Charger with USB-C (45W), SAE connector, 10-30V DC input (RAM-GDS-CHARGE-V3C-3U) is equally suitable for cars, vans and commercial vehicles. Typical application areas include field service, fleet use, warehousing and mobile workstations. The built-in protection against overvoltage, short circuit and reverse polarity ensures reliable operation in demanding everyday use.
Technical details RAM Mounts GDS Hardwire Charger USB-C 45W PD SAE Connector
- Input voltage: 10-30V DC
- Output voltage: 5-15V DC
- Output current: 3A max.
- Connector: USB Type-C (male)
- Input cable length: approx. 250 cm
- Output cable length: approx. 100 cm
- Operating temperature: -20°C to +70°C
- Storage temperature: -40°C to +85°C
- Protection: overvoltage, short circuit, reverse polarity
- Supports USB Power Delivery 3.0
- Certifications: FCC, CE, RCM, WEEE, RoHS, UL62368-1, SAE J-1113-5
Ensure that the RAM GDS DC/DC power supply and all USB sockets (if present) are mounted at least 1 meter (40 inches) away from any radio or other high-power RF device that emits more than 5 W of RF power.
| Manufacturer/Importer: | RAM Mounts Germany GmbH, Alexander-Meissner-Str. 42, 12526 Berlin, info@rammounts.de |
|---|---|
| USB-Charger: | USB C |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
Download area - catalogs, flyers, warranty conditions, ...
Questions & Answers
-
What is the RAM Mounts GDS Hardwire USB-C Charger (45W) with PD?
The ideal solution for powering compatible USB-C GDS vehicle mounts. It connects via the SAE connector to the vehicle power source and supports USB Power Delivery 3.0 (45W).
-
What input voltage does it require?
Input voltage: 10-30V DC.
-
What output and power delivery does it provide?
Output is 5-15V DC, up to 3A max; USB Type-C (male) connector; supports USB Power Delivery 3.0 (45W).
-
Which vehicles and use cases is it suitable for?
Suitable for cars, vans and commercial vehicles; use cases include field service, fleets, warehousing and mobile workstations.
-
What are the cable lengths and connection details?
Input cable length around 250 cm; output cable length around 100 cm; USB-C is a male plug.
-
What protections and certificates does it have?
Protection against overvoltage, short circuit and polarity; Certifications: FCC, CE, RCM, WEEE, RoHS, UL62368-1, SAE J-1113-5.
-
Any safety or installation notes?
Ensure the RAM GDS DC-DC power supply and all USB ports are mounted at least 1 metre away from any radio or high-power HF equipment emitting more than 5 W.
RAM Mounts GDS Hardwire Charger USB-C – reliable power supply in the vehicle
The RAM Mounts GDS Hardwire Charger RAM-GDS-CHARGE-V3C-3U was specially developed for professional use in vehicles and provides stable power for compatible GDS vehicle mounts with a USB-C connection. Whether in a van, on a forklift or in an emergency vehicle – this hardwire charger connects easily to the vehicle battery via the SAE connector and ensures a safe, continuous charging process. With a wide input voltage range of 10–30V DC, it can be used universally in 12V and 24V vehicles. The Power Delivery function with up to 45W enables fast charging of modern USB-C-capable devices such as tablets, smartphones or rugged industrial handhelds. Thanks to USB Power Delivery 3.0, the optimal charging power is negotiated automatically between charger and device, ensuring maximum efficiency and battery care. Integrated safety circuits reliably protect device and vehicle from overvoltage, short circuit and reverse polarity – even under extreme temperature conditions from -20°C to +70°C. With an input cable length of approx. 250 cm and an output cable length of approx. 100 cm, the hardwire charger offers sufficient leeway for neat cable routing inside the vehicle.
What is the RAM-GDS-CHARGE-V3C-3U suitable for?
The GDS hardwire charger is ideal for users who need to operate and charge mobile devices permanently in vehicles. Typical areas of use include delivery and transport services, emergency services, fire departments, police, field service personnel as well as industrial and logistics companies with vehicle fleets. The RAM Mounts GDS Hardwire Charger with USB-C (45W), SAE connector, 10–30V DC input (RAM-GDS-CHARGE-V3C-3U) is fully compatible with the entire RAM GDS ecosystem and can be easily integrated into existing vehicle installations. Certifications FCC, CE, RCM, WEEE, RoHS, UL62368-1 and SAE J-1113-5 attest to the high quality and international standards compliance of the product. RAM Mounts has stood for robust, durable mounting and charging technology in vehicles for decades – the GDS hardwire charger is further proof of that.
How is the GDS hardwire charger installed in the vehicle?
Installation of the RAM Mounts GDS Hardwire Charger RAM-GDS-CHARGE-V3C-3U is simple and quick: the SAE connector of the long input cable (approx. 250 cm) is connected directly to the vehicle power source or battery. The shorter output cable (approx. 100 cm) connects the charger to the compatible GDS vehicle mount. RAM Mounts recommends mounting the device and all USB ports at least 1 meter away from high-power RF devices that emit more than 5W of RF power. This ensures interference-free operation even in vehicles with radios or other RF equipment. The GDS hardwire charger USB-C is the professional choice for those who demand the highest reliability, charging speed and vehicle suitability.
