RAM Mounts suction cup set with C-ball and round base plate (RAM-224-3U)
Highlights
- Triple suction cup for extra hold
- C-ball 1.5-inch mount
- Round AMPS base plate included
- For smooth, non-glossy surfaces
- Load capacity up to approx. 1.8 kg
RAM Mounts Triple Suction Cup Mount with AMPS Base Plate
The RAM Mounts suction cup kit with C-ball and round base plate (RAM-224-3U) consists of a triple-suction-cup base with a C-ball (1.5 inches) and a round AMPS base plate. The three suction cups, each 83.8 mm in diameter, provide particularly stable mounting on smooth, non-porous surfaces such as windshields or plastic panels. The kit is ideal for use in vehicles, boats, and industrial environments.
The construction of powder-coated steel and high-strength composite ensures a high load capacity of up to 1.8 kg under intensive use. The round base plate with AMPS hole pattern allows mounting of numerous device holders. The suction cup mount can be easily attached and released thanks to the twist lock.
Technical Details RAM Mounts Suction Cup Kit
- Suction cups: 3x 83.8 mm diameter, overall width approx. 202 mm
- Ball diameter: 38.1 mm (1.5 inches, C-ball)
- Load capacity: up to approx. 1.8 kg (standard), up to approx. 1.4 kg (heavy-duty)
- Material: powder-coated steel, high-strength composite
- Color: black
- Weight: approx. 533 g
- Packaging: polybag
| Material: | Pulverbeschichteter Stahl, Hochfestigkeits-Verbundstoff |
|---|---|
| Warranty: | 30 Jahre |
| Manufacturer/Importer: | RAM Mounts Germany GmbH, Alexander-Meissner-Str. 42, 12526 Berlin, info@rammounts.de |
| Mounting type: | Car mount |
| color: | Black |
| RAM Mounts Kugel: | C-Kugel |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
Download area - catalogs, flyers, warranty conditions, ...
Questions & Answers
-
What is included in the RAM Mounts suction foot set RAM-224-3U?
It consists of a triple suction cup base with a 1.5-inch C-ball and a round AMPS base plate. It also includes three suction cups, each 83.8 mm in diameter.
-
What is the payload capacity?
Payload up to about 1.8 kg (Standard); about 1.4 kg (Heavy-Duty).
-
Which surfaces can it be mounted on?
Designed for smooth, non-porous surfaces such as windshields or plastic panels.
-
What material is it made from and what colour is it?
Made of powder-coated steel and high-strength composite; colour is black.
-
Where is it suitable to use?
Ideal for use in vehicles, boats and industrial environments.
-
How do you attach and detach the suction foot mounting?
The suction-cup mount can be mounted and released easily with a twist-lock.
-
What is the ball size and base plate pattern?
Ball diameter is 38.1 mm (1.5 inch) C-ball; round AMPS base plate.
-
What are the dimensions and weight?
Overall width about 202 mm; weight about 533 g; packaging: poly bag.
What does the RAM Mounts suction cup set RAM-224-3U offer?
The RAM Mounts suction cup set RAM-224-3U combines three powerful suction cups with a round AMPS base plate and a C-ball (1.5-inch) size. By combining three suction cups each with a diameter of 83.8 mm, a particularly stable connection on smooth, non-porous surfaces is created. The total width of the suction cup base is approx. 202 mm, providing a large contact area for maximum hold. The construction of powder-coated steel and high-strength composite guarantees a load capacity of up to 1.8 kg in standard use. The round base plate with AMPS hole pattern allows mounting a variety of device holders and adapters from the RAM Mounts range.
On which surfaces does the triple suction cup adhere optimally?
The RAM Mounts triple suction cup RAM-224-3U is designed for optimal hold on smooth, non-porous surfaces. Best results are achieved on glass or non-porous plastic, such as windshields, side windows or smooth plastic panels. For slightly textured surfaces, the optional adhesive pad is recommended as additional adhesion reinforcement. The twist-lock mechanism creates a strong vacuum that reliably holds even under vibration and temperature changes. Before mounting, both the surface and the suction cups should be thoroughly cleaned to achieve the best possible adhesion.
Which devices can be mounted with the suction cup set?
The RAM Mounts suction cup set RAM-224-3U is suitable for mounting various electronic devices in vehicles, on boats and in industrial environments. Typical applications include attaching tablets, navigation devices, fish finders or monitors to windshields or cockpit panels. The AMPS base plate is compatible with a wide range of mounting arms and device cradles. Thanks to the load capacity of up to 1.8 kg, larger devices can also be mounted securely. The modular RAM Mounts system allows the suction cup to be combined with various swivel arms and ball mounts.
