RAM Mounts VESA Assembly Kit - 2x VESA plate (75x75 mm), medium connecting arm, C-ball (RAM-102U-2461)
Highlights
- 2x VESA plate 75 x 75 mm
- Middle connecting arm approx. 140 mm
- C-ball 1.5-inch system
- Total height approx. 187 mm
- Powder-coated aluminum
RAM Mounts VESA mounting set with medium connecting arm
The RAM Mounts VESA setup kit - 2x VESA plates (75x75 mm), medium connecting arm, C-ball (RAM-102U-2461) consists of two VESA plates with a 75 x 75 mm hole pattern and a medium connecting arm (approx. 140 mm). The VESA plates have a base area of 92.08 x 92.08 mm. The C-balls (1.5 inch) have an offset from the corner center point of 22.35 mm.
The patented ball-and-arm system enables mounting for almost any viewing angle. The overall height of the set is approx. 186.7 mm and thus provides a greater distance than the short-arm variant. The set is ideal for monitor mounting in vehicles, on boats and in industrial applications.
Technical details RAM Mounts VESA set medium arm
- Overall height: approx. 186.7 mm
- Connecting arm: approx. 140 mm
- VESA plates base area: 92.08 x 92.08 mm
- VESA hole pattern: 75 x 75 mm
- Ball diameter: 38.14 mm (1.5 inch, C-ball)
- Material: powder-coated aluminum
- Color: black
- Weight: approx. 680 g
- Packaging: polybag
| Material: | Pulverbeschichtetes Aluminium |
|---|---|
| Warranty: | 30 Jahre |
| Manufacturer/Importer: | RAM Mounts Germany GmbH, Alexander-Meissner-Str. 42, 12526 Berlin, info@rammounts.de |
| Mounting type: | Car mount |
| color: | Black |
| RAM Mounts Kugel: | C-Kugel |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
Download area - catalogs, flyers, warranty conditions, ...
Questions & Answers
-
What does the RAM Mounts VESA assembly set RAM-102U-2461 include?
It comprises two VESA plates (75 x 75 mm), a middle connecting arm (approx. 140 mm) and a C-ball, RAM-102U-2461.
-
What are the dimensions of the VESA plates?
VESA plate footprint is 92.08 x 92.08 mm; hole pattern 75 x 75 mm.
-
What is the total height of the set?
Approximately 186.7 mm tall, providing a larger distance than the short-arm variant.
-
How long is the middle arm?
The middle connecting arm is approx. 140 mm long.
-
What is the ball diameter?
Ball diameter is 38.14 mm (1.5 inches).
-
What material and colour is the set?
Made of powder-coated aluminium; colour is black.
-
What is the weight and packaging?
Weight approx. 680 g; packaging in poly bag.
-
What are the intended applications?
Suitable for monitor mounting in vehicles, on boats and in industrial applications.
What does the RAM Mounts VESA set RAM-102U-2461 offer?
The RAM Mounts VESA assembly set RAM-102U-2461 combines two VESA plates with a 75 x 75 mm hole pattern and a middle connecting arm of approx. 140 mm length into a complete mounting set for monitors and displays. The VESA plates each have a base area of 92.08 x 92.08 mm and the C-balls have a distance to the corner center point of 22.35 mm. The total height of the set is approx. 186.7 mm, offering significantly more reach than the short variant RAM-102U-B-2461 with approx. 165 mm. The powder-coated aluminum provides durability and corrosion resistance even under intensive professional use. The total weight of approx. 680 g offers an optimal compromise between stability and ease of handling.
What advantages does the middle connecting arm offer compared to the short one?
The middle connecting arm of the RAM Mounts VESA set RAM-102U-2461 offers approx. 140 mm, significantly more length than the short arm of the RAM-102U-B-2461 variant at approx. 90 mm. This additional distance of approx. 50 mm enables more flexible monitor positioning and a larger swivel range. In vehicles, the monitor can be positioned further away from the dashboard and brought closer to the driver. On boats, the display can be moved closer into the helmsman’s field of view without relocating the mounting base. The total height of approx. 186.7 mm compared to 165 mm provides noticeably more flexibility in positioning. At the same time, the middle arm remains compact enough not to obstruct the work area. For applications that require even more reach, long connecting arms are available in the RAM Mounts range.
For which applications is the VESA mounting set suitable?
The RAM Mounts VESA assembly set RAM-102U-2461 is suitable for versatile professional applications in vehicles, on boats and in industry. In vehicles it is used to mount monitors for navigation, rearview cameras, fleet management displays or entertainment systems. On boats, fishfinder displays, chartplotters and communication monitors are securely mounted and can be continuously adjusted to the optimal viewing position. In industrial environments, the set is used to mount control monitors to machine frames, POS systems in retail and workstation displays at benches. The patented ball-and-socket arm system enables continuous adjustment of the viewing angle with a single locking knob. The load capacity of the C-ball system of up to 1.8 kg in standard use is sufficient for most smaller monitors and specialist displays. RAM Mounts’ 30-year warranty underlines the high quality and durability of this mounting set. The middle connecting arm offers a significantly greater reach compared to the short arm of the RAM-102U-B-2461 variant, allowing the monitor to be positioned more flexibly and brought closer to the operator. The VESA plates are attached to the monitor and the mounting base with standard M4 screws. Thanks to the modular design of the RAM Mounts system, the middle arm can be swapped out for a short or long arm if required without changing the VESA plates. The individual components are also available separately and can be combined with other elements from the range. The shock-absorbing rubber balls of the patented system absorb vibrations and shocks, protecting the monitor from mechanical damage and ensuring a stable image display. Packaging is in a polybag.
