Bachmann 19 inch power strip 5x sockets full protection 1,5U (333.002)
The Bachmann power strip 333.002 is a 19inch PDU power strip with 1,5U Alu-Profile for the power distribution at a Datacenter or to be integrated into your IT rack. The power distribution unit contains 5x german type socket outlets and devices full protection with a 2,0m power supply cable with right-angled earthing contact plug.
Bachmann 19 inch power strip 1,5U 5x socket outlets (333.002)
With its IT PDU Basic 1,5U, BACHMANN provides a huge choice of PDUs in a high-quality aluminium profile. With their extremely compact size of just 1,5 height units and 44 mm in depth the power distribution unit 333.002 can be easily integrated into your IT rack. Their multi-functional mounting brackets allow the units to be easily mounted in various ways (e.g. inwardly recessed).
Key features Bachmann IT PDU power strip 1,5U 5x socket outlets (333.002)
- IT PDU Basic 1,5U (230V / 50Hz)
- Plug: right-angled earthing contact plug
- 5x socket outlets german type, 35° twisted, white
- 1x full protection
- Dimensions: 440 x 52 x 44 mm
- Power supply: 2,0m H05VV-F 3G 1,50 mm²
- Rated voltage: 230V
- Incl. 2x mounting metal flanges
- End caps riveted
- Finish profile: white
Note DGUV V3: According to DGUV V3, permanently screwed / stationary power strips must be checked every 4 years by a qualified electrician in accordance with DIN VDE 0100-600. Portable power strips must be checked annually. Further information can be found in the download area under "Manufacturer's declarations"
| Product sheet: |  [pdf, 1,2 MB] |
|---|---|
| RoHS / REACH: | [pdf, 110 kb] |
| Warning/safety instructions: | [pdf] |
| Contains installation material: | + |
| Manufacturer/Importer: | Bachmann GmbH, Ernsthaldenstr. 33, 70565 Stuttgart, info@bachmann.com |
| Number of sockets: | 5 |
| color: | Weiß |
| Land: | Germany |
| screw-on: | Yes |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
Download area - catalogs, flyers, warranty conditions, ...
