MonLines MPH001 Pivot 90° rotatable adapter plate VESA 100x100 mm
The MonLines MPH001 VESA Adapter with the VESA standard of 100x100mm allows a pivot function of the monitor on all monitor mounts with a VESA mount of 100x100mm.
VESA Adapter monitor mount rotatable
A VESA standard is defined for the application of mounting television or monitor screens. The VESA monitor mount, also known as the VESA standard, is affixed to the rear of the monitor or TV screens, typically featuring four holes. VESA adapters like the MPH001 are designed to be attached to the VESA mount. These adapters can modify the VESA spacing or enable screen rotation, making the monitor adaptable for use with any screen mount. The MonLines VESA adapter, which can rotate 90 degrees, is installed using screws between the existing 100x100 VESA mount on the monitor and the monitor mount.
VESA adapter plate with pivot function
The MonLines MPH001 VESA adapter provides the capability to pivot the screen 90 degrees on the mount, accommodating screens up to 32 inches in size. This adapter plate is universally compatible with any display or monitor mount that features a 100x100 mm VESA mount. Furthermore, the VESA adapter plate is coated with a high-quality black powder finish and has a maximum load-bearing capacity of 5 kg.
Key features MonLines MPH001 pivot adapter plate VESA 100x100 mm
- VESA mount: 100x100 mm
- Material: steel
- Rotation by 90 degrees (pivot function) around its own axis
- Rotation limited to 90 degrees adjustable to left or right
- High quality powder coating
- Colour: black
Attention: Only the adapter plate is included in the delivery. The monitor holder must be purchased separately.
Does this VESA adapter fit your monitor?
If your monitor does not have a VESA mounting hole pattern, a VESA adapter will help. We will be happy to check if this MonLines MPH001 VESA Adapter is suitable for your monitor. Simply send us your model (manufacturer + model no.) in the comment field at the end of the order process. We will then check whether the VESA adapter plate fits your monitor and if not, we will contact you.
VESA Standard - Learn more about the VESA standard!
| Product sheet: |  [pdf] |
|---|---|
| Technical drawing: | [pdf] |
| RoHS / REACH: | [pdf] |
| Rotate: | 90° |
| Pivot: | Ja |
| Material: | steel |
| VESA Standard: | 100x100 mm (www.vesa-standard.com) |
| Manufacturer/Importer: | BCS Business Creative Solutions GmbH / MonLines, Am Marienhof 8, 22880 Wedel, info@monlines.de |
| Mobility: | rotatable (pivot) |
| color: | Black |
| VESA (in mm): | VESA 100x100 |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
Download area - catalogs, flyers, warranty conditions, ...
1 review
10 July 2024 13:43
Endlich die Lösung gefunden
Prompte Lieferung, ich konnte den Adapter schon 3 Tage später in Betrieb nehmen. Ich benutze Die Drehfunktion je nachdem, ob ich gerade Programme entwickle oder Dokumente lese. Nach sowas habe ich schon länger gesucht. Sehr empfehlenswert!
